Anchor bolts in wood sill plates
Here is a strange 'What was the Code thinking?' question...
In the NDS spec, section 11.5.1 deals with minimum bolt edge/end distances and spacings. 11.5.1.3 and Table 11.5.1.C states that the minimum edge distance needs to be 4D from the center of a bolt. So this begs the question, what do you do with 2x4 wall sill plates? Using a standard 5/8' anchor bolt centered in the wall, you don't meet the minimum 4D requirement, nor do you using the minimum 1/2' anchor bolt required by the IBC. So, whether intentional or not, the code is basically implying you cannot use 2x4 walls with anchor bolts that are subject to out-of-plane loads.
I'm just designing a little multi-stall garage, but it is taking a decent amount of out-of-plane load (100+ mph winds) especially at the king studs. Has anyone dealt with this code issue before or am relegated to using a 2x6 wall? I certainly wouldn't mind it but the architect might...
Thanks.
In the NDS spec, section 11.5.1 deals with minimum bolt edge/end distances and spacings. 11.5.1.3 and Table 11.5.1.C states that the minimum edge distance needs to be 4D from the center of a bolt. So this begs the question, what do you do with 2x4 wall sill plates? Using a standard 5/8' anchor bolt centered in the wall, you don't meet the minimum 4D requirement, nor do you using the minimum 1/2' anchor bolt required by the IBC. So, whether intentional or not, the code is basically implying you cannot use 2x4 walls with anchor bolts that are subject to out-of-plane loads.
I'm just designing a little multi-stall garage, but it is taking a decent amount of out-of-plane load (100+ mph winds) especially at the king studs. Has anyone dealt with this code issue before or am relegated to using a 2x6 wall? I certainly wouldn't mind it but the architect might...
Thanks.
Sill plate anchor requirement
Sill plate anchor requirement
J Plates Anchor Plate
Have a basic question regarding wood sill plates for which I can't seem to track down an exact source. According to NDS Table 8.5.3 the minimum edge distance for a bolt loaded perpendicular to grain is 4D for loaded edge and 1.5D for unloaded edge. For a wall subjected to wind pressures (positive and negative directions), this 4D requirement technically prevents the use of 1/2' diameter bolts in a 2x4 sill plate, since half of 3.5 inches is less than 4D distance. Of course, 1/2' and even 5/8' bolts are commonly used as anchor bolts. Can anyone help clear up the apparent conflict?
